Max Performance, Minimalist Design

NCORE 100 MAX

Cooler Master’s NCORE 100 MAX is the ultimate solution for going big on performance in the minimal amount of desktop space.

The Compact Case for Powerful PC

Discover the NCORE 100 MAX by Cooler Master: a compact, high-performance addition to the MAX series. It offers advanced cooling, power solutions, and a small form factor with anodized aluminum panels. Accommodating up to 3.9 Slot GPU, it ensures compatibility with the latest processors, delivering unparalleled performance without sacrificing design. Experience versatility, compatibility and peak performance with the sleek, space-saving NCORE 100 MAX.

Elevate your setup today!

Tech Specs

Product Number

NCORE 100 MAX: NR100-MNNN85-SL0, NR100-MNNN85-SL1

Product Number

NCORE 100 MAX Bronze Edition: NR100-ZNNN85-SL0, NR100-ZNNN85-SL1

Exterior Color

NCORE 100 MAX: Dark grey

Exterior Color

NCORE 100 MAX Bronze Edition: Bronze

Materials - Exterior

Steel, Plastic, Aluminum

Materials - Side Panel

Aluminum

Dimensions (L x W x H)Normal mode: 155mm x 212mm x 481mm (Incl. Protrusions)Dimensions (L x W x H)Expansion mode: 172mm x 212mm x 481mm (Incl. Protrusions)Dimensions (L x W x H)155mm x 212mm x 457mm (Excl. Protrusions)Dimensions (L x W x H)172mm x 212mm x 457mm (Excl. Protrusions)

Volume15.80L (Normal mode)
Volume17.54L (Expansion mode)
Motherboard SupportITX
Expansion Slots3x PCIe Slot Mounting
Drive Bays - 2.5" SSD1
I/O Panel2x USB 3.2 Gen1 Type A
I/O Panel1x USB 3.2 Gen2 x 2 Type C
I/O Panel1x Audio Combo (Audio In / Out 3.5mm)
Pre-Installed Accessories1x 240mm PCIe 4.0 x16
Pre-Installed CPU Cooling Solution120mm Radiator with 38mm Thickness x 1 (Custom PWM Fan Max. 2400RPM)
Pre-installed Power Supply UnitV SFX Gold 850W ATX 3.0
Pre-installed Fan(s) - Rear120mm SickleFlow PWM Fan x1 (Max. 1800RPM)
Clearances - CPU Cooler48mm
Clearances - Power Supply100mm
Clearances - RAM48mm
Clearances - Graphics Card337mm x 62mm x 180mm (Normal, 3.0 Slot thick)
Clearances - Graphics Card357mm x 79mm x 180mm (Expansion, 3.9 Slot thick)
Clearances - Graphics Card(Maximum space including GPU power connector)
Cable Routing - Behind MB Tray11mm
Dust FiltersSide panels
Power Supply SupportSFX
Warranty2 years (Case), 2 years (Thermal Solution), 10 years (Power Delivery)
SizeMini ITX
