Hikvision DS-M7508HNI/GW/WI — Mobile NVR
Hikvision DS-M7508HNI/GW/WI — Mobile NVR
Regular price
R 18,260.87
Regular price
Sale price
R 18,260.87
Unit price
/
per
Price incl. VAT (15.0%):R 21,000.00
Shipping calculated at checkout.
Couldn't load pickup availability
Hikvision DS-M7508HNI/GW/WI — Mobile NVR (8-ch PoE, 3G + Wi-Fi + GPS)
Technical Specs
| Model | DS-M7508HNI/GW/WI |
|---|---|
| IP Video Input | 8-channel, PoE supported |
| Incoming Bandwidth | 160 Mbps |
| Recording Resolution | 1080p / 720p |
| VGA Output | 1-ch up to 1920×1080@60 Hz |
| CVBS Outputs | 3-ch (aviation plug), PAL 704×576 / NTSC 704×480 |
| Audio Output | 3-ch (aviation plug, 600 Ω) |
| Two-Way Audio | 1-ch, G.722 |
| Decoding | Live view 8-ch; synchronous playback 1-ch |
| HDD/SSD | 2 × 2.5″ SATA (7 mm); pluggable anti-vibration HDD box |
| Capacity | Up to 2 × 1 TB |
| Backup | Hard disk box, USB 2.0, and eSATA |
| Wireless (this model) | 3G WCDMA dialing; Wi-Fi 802.11 b/g/n (2.4 GHz) |
| Positioning | GPS (GNSS) |
| Network I/O | 1 × RJ45 10/100; 8 × RJ45 10/100 PoE for cameras |
| Alarms | 7 × alarm-in + 1 × pulse; 2 × alarm-out |
| Serial | RS-232, RS-422 (aviation plugs) |
| Other I/O | 1 × eSATA; 1 × USB 2.0; 2 × SIM slots |
| Power | +8 to +36 VDC input; 12 VDC/2 A & 5 VDC/1 A outputs |
| Power Consumption | Standby ≤ 0.5 W; Full load ≤ 20 W (no HDD/cameras) |
| Operating Temp | Enterprise HDD: −10 °C to +55 °C; Industrial HDD: −20 °C to +60 °C |
| Humidity | 10%–90% |
| Dimensions (W × D × H) | 245.8 × 202 × 86.87 mm |
| Weight | ≤ 3.3 kg (without HDD) |
| Certifications | CE, FCC, E-MARK, EN50155, EN45545, Vibration Test (ILAC-MAR, CNAS) |
Courier / Shipping
| Retail Box Dimensions | — Not published by Hikvision |
|---|---|
| Retail Box Weight | — Not published by Hikvision |
